CS-682G Kit
CH6 / T1002 / GS-3 / S-52The CS-682G Professional Tripod System includes a 100mm CH6 fluid head, T1002 aluminum tripod, GS-3 ground spreader, and an S-52 carry case.
The CS-682G Professional Tripod System from Acebil includes a 100mm CH6 fluid head, T1002 aluminum tripod, GS-3 ground spreader, and an S-52 carry case. The tripod features a two-stage design and aluminum construction that supports loads up to 15kg / 33.0lb. It provides a height range from 63-171cm / 24.8”-67.4” and comes equipped with a sliding quick-release plate and pan bar.
- 100mm ball
- Single Stage Aluminum Tripod
- Supports loads up to 15kg / 33.0lb
- Height range: 63-171cm / 24.8”-67.4”
| Payload | 15kg / 33.0lb |
|---|---|
| CB Payload | 2~12kg / 4.4~26.4lb |
| Counter Balance | Free + 8 Steps |
| Pan Drag | Free + 6 Steps |
| Tilt Drag | Free + 6 Steps | Tilt Angle | +90° / -70° |
| LED Bubble Level Illumination | Yes |
| Camera Plate | Slide Plate |
| Plate Attachment | 3/8" Screw |
| Spare Camera Screw | 1/4" & 3/8" Screw | Slide Range | +60 / -60 mm |
| Weight | 7.2kg / 15.9lb |
| Height | 63-171cm / 24.8”-67.4” |
| Ball Diameter | 100mm |
| Leg Section | 2 Stage |
